Julius’ drawings for an oscillating engine and boiler steam plant, a great project for beginners.

Click on drawings to download.

For personal use only.

Although drawings reproduce well on this website, they are better as saved downloads. To better view these drawings, download the pdfs, magnify, and frame the area required. For workshop use, send files to a plan printer for printing on paper in the appropriate size (see information panel on drawing).

As usual with Julius’ designs it can be constructed without castings.

Why not download it now - make it easier to find later!

Please let the editor know if you are building one of these or other projects to Julius’ drawings.
