News and editorial

By David Carpenter

GARRETT TRACTION ENGINE

Julius’ full set of drawings for a  Garrett traction engine - a major new project.


3D TURBINE LOCO CAB

Thinking outside the box to produce complex shapes using 3D printing in a less than obvious way.


5” GAUGE KOPPEL LOCO

MEWS’ Model of the Week is a delightful Polly Koppel loco in 5” gauge.


COMPOUND DUPLEX ENGINE

Special feature on another great original Julius design from Rafel Ayensa, a fascinating compound duplex engine. Don’t miss it on YouTube.



COMPOUND ENGINE AND DYNAMO

Our delve into the archives turns up an interesting early compound engine and dynamo.


JAMES COOMBES ENGINE REVISITED

Jason Ballamy’s classic engine for fabricated construction, the great James Coombes.


ENGINEERING IN MINIATURE TO FOLD

It was sad to hear from Engineering in Miniature that it will cease publication with the next issue, published in April. May of us remember the excitement caused in 1979 when the late Chris Deith published the first issue with super subjects, great contributors and exemplary drawings printed on really good paper. And so it continued under his direction for decades until being sold to its current publishers, Warners Group.

Editor, Andrew Charman, writes in the current issue:

“While I have no doubt that this news will be as disappointing to readers as it is to myself, I admit to not being greatly surprised by the decision. In today’s environment it has become increasingly difficult to keep producing the standard of magazine that you are used to and expect from us. I see  it in the amount of feature material I receive  -  attracting sufficient has become an ever growing challenge in the six years that I have been at the helm of EIM. Crucially the publishers see the growing difficulty in attracting enough readers and advertisers to the magazine.”

Andrew will have more to say in the final issue.
