Some years ago we published drawings for this engine and it has proved popular. With new readers joining us since, we decided to publish it again. Makes a good beginner’s engine. or a ‘quickie’ project.

Suitable boilers here.

Click on drawing to download.

For personal use only.

Although drawings reproduce well on this website, they are even better as saved downloads.

Please let the editor know if you are building one of these or other projects to Julius’ drawings.
